Lightbox

<msc-lightbox /> is a lightbox effect component. Developers could set trigger & content through it. Once user press trigger, content will display as lightbox effect.

Check the following buttons and take a look what can <msc-lightbox /> do ?

Tutorial

Chekc the following tutorial and see how <msc-lightbox /> work.

Basic Usage

<msc-lightbox /> is a web component. All we need to do is put the required script into your HTML document. Then follow <msc-lightbox />'s html structure and everything will be all set.

Required Script

<script type="module" src="https://unpkg.com/msc-lightbox/mjs/wc-msc-lightbox.js"> </script>

Structure

Put <msc-lightbox /> into HTML document.

<msc-lightbox> <button type="button" slot="trigger" > SHOW IMAGE </button> <img src="your-image-path.png" loading="lazy" slot="content" /> </msc-lightbox>

Remember set [slot=trigger] and [slot=content] inside <msc-lightbox /> as its children. Content element will popup when user press trigger element.

JavaScript Instantiation

<msc-lightbox /> could also use JavaScript to create DOM element. Here comes some examples.

<script type="module"> import { MscLightbox } from 'https://unpkg.com/msc-lightbox/mjs/wc-msc-lightbox.js'; const templateTrigger = document.querySelector('template[data-type=trigger]'); const templateContent = document.querySelector('template[data-type=content]'); //use DOM api const nodeA = document.createElement('msc-lightbox'); document.body.appendChild(nodeA); nodeA.appendChild(templateTrigger.content.cloneNode(true)); nodeA.appendChild(templateContent.content.cloneNode(true)); // new instance with Class const nodeB = new MscLightbox(); document.body.appendChild(nodeB); nodeB.appendChild(templateTrigger.content.cloneNode(true)); nodeB.appendChild(templateContent.content.cloneNode(true)); </script>

Style Customization

<msc-lightbox /> uses CSS custom properties to hook control panel's theme. That means developer could easy change it into the looks you like.

<style> msc-lightbox { --msc-lightbox-backdrop-background: rgba(0 0 0/.8); --msc-lightbox-border-radius: 12px; --msc-lightbox-background: rgba(255 255 255); --msc-lightbox-margin: 12px; --msc-lightbox-padding: 12px; --msc-lightbox-box-shadow: 0 0 2px rgba(0 0 0/.05); --msc-lightbox-button-size: 40; --msc-lightbox-button-inset: 8px 8px auto auto; --msc-lightbox-button-icon-color: rgba(255 255 255); --msc-lightbox-button-background-normal: rgba(0 0 0/.5); --msc-lightbox-button-background-active: rgba(0 0 0/.8); --msc-lightbox-button-active-scale: .8; } </style>

Attribute

<msc-lightbox /> supports some attributes to let it become more convenience & useful.

type

Same as popover definition. The type attribute can take one of the following values:

- auto：<msc-lightbox /> can be "light dismissed" — this means that you can hide the popover by clicking outside it or pressing the Esc key. Showing an auto popover will generally close other auto popovers that are already displayed, unless they are nested.
- manual：<msc-lightbox /> cannot be "light dismissed" and are not automatically closed. Popovers must explicitly be displayed and closed using declarative show/hide/toggle buttons or JavaScript. Multiple independent manual popovers can be shown simultaneously.
- hint：<msc-lightbox /> do not close auto popovers when they are displayed, but will close other hint popovers. They can be light dismissed and will respond to close requests.

The default is auto.

<msc-lightbox type="auto"> ... </msc-lightbox>

Properties

Property Name Type Description
open Boolean Getter <msc-lightbox />'s open state.
type String Getter / Setter <msc-lightbox />'s type value. Valid values are auto、manual and hint. The default is auto.

Events

Event Signature Description
msc-lightbox-beforetoggle Fired before <msc-lightbox /> is shown or hidden. Developers could gather state information through event.detail.
msc-lightbox-toggle Fired when <msc-lightbox /> is shown or hidden. Developers could gather state information through event.detail.

Mathods

Mathod Signature Description
showPopover() Show <msc-lightbox />.
hidePopover() Hide <msc-lightbox />.
togglePopover(force) Toggle <msc-lightbox /> show or hide. (force is optional, developers could set boolean to force show or hide.)
